Power Operated Paddy Thresher with side lower Separate Electric Winnower Fan Attach Complete

Power Operated Paddy Thresher with side lower Separate Electric Winnower Fan Attach Complete 3.5 FT Iron Strips Body SP-3.5 BBPW-SEFA 13/I

₹21,500.00

MODEL No. SP-3.5 BBPW-SEFA 13/I

Main Drum Attach With 0.5-1 HP Motor Or 2-3 HP Engine Operated Separate Electric Fan Attach With 0.25 HP Motor Operated
Straight / Flat Iron Strips – 12/13/15
➤ Output Capacity: 400-500 Kg / Hr.
➤ Rpm: 300-350 (Approx.)
➤ Power: Motor/Engine (Two / Three Person) (Approx.)

Shipping 7 to 10 days

Sale 10% all products

For Enquiry
Add to wishlist
SKU: SP-3.5 BBPW-SEFA 13/I Category:
Share Product

Description

Technical Specification:

► MS Fabricated Body Angel & Body Sheet (mm): 38/3, 30/3, 25/3 & 0.4-0.5
► Dimensions of Body (LXWXH) (mm): 1060 × 585 x 760
► Cylinder Size (DXL) (mm): 400 × 910
► Shaft (DXL) (mm): 25 x 1215
►Bearing Block Type & Bearing Size: CI UCP 205 / CI Plummer Block 1205
► Wheel Material: (CI Casting / MS Sheet Wheel / MS Ring Wheel)
► Loop Wire Diameter (mm): 4-6 (Carbon Steel)
►Number of Wire Loops: 18 × 12/13/15
►Number of Wire Loop Strips: 12/13/15
►Number of Fan Blade & Size: MS- Three Blade & 18 Inch. Dia (Seperate Electric Fan) Number of Base Wheel & ►Wheel Size: 4 Nos. 4 Inch. Rubber Wheel Attach in Bottom Base
► Transmission System: Power From Different Source
► Mechanism With: Main Drum attach with 0.5-1 HP Motor Or 2-3 HP Engine & Electric Fan attach with 0.25 HP Motor

Additional information

Model

SP-3.5 BBPW-SEFA 12/W, SP-3.5 BBPW-SEFA 13/W, SP-3.5 BBPW-SEFA 15/W, SP-3.5 BBPW-SEFA 12/I, SP-3.5 BBPW-SEFA 13/I, SP-3.5 BBPW-SEFA 15/I
